It lets the operator choose the basic type of work to be done from clear illustrations, and then presents a clear, step-by-step process for defining how the part should be cut. The Mastercam X5 multi-axis suite has new machining techniques and a simple workflow-oriented interface.

Mastercam X5 includes a new high-speed technique for generating toolpaths: OptiRough is designed to remove large amounts of material quickly using dynamic milling motion. It also supports multi-passes and can optionally include finishing passes, the developer notes.

Dynamic Contour uses an intelligent, high-speed contouring strategy to remove material along walls efficiently.

Dynamic Rest Mill behaves in a manner similar to the current toolpath, except that it uses a dynamic milling motion rather than a core mill or area mill motion for the rest operations.

New dynamic milling techniques in Mastercam X5 include Dynamic Rest Mill and Dynamic Contour. It also makes use of the entire length of a tool, often eliminating the need for multiple depth cuts. ”Dynamic milling” is a capability for constant adjustment of a toolpath to ensure the most efficient cut that is possible.

These new functions include new dynamic milling techniques, multi-axis machining, and Smart Hybrid Finishing, among others. CNC Software is introducing some notable new capabilities with the release of Mastercam X5, the latest iteration of its job-shop-focused CAD/CAM software series.
